400-3000MHz Broadband Wide Band 50W RF Power Amplifier Module
This 400-3000MHz RF Module 50W Power Amplifier is a no signal source power amplifier module delivering 50W output power. Available in multiple frequency ranges including 400-3000MHz, 2500-6000MHz, and 6000-8000MHz RF PA configurations.
Key Features
Ultra-Wideband Performance
Seamless coverage from 400MHz to 3000MHz, eliminating the need for multiple narrow-band amplifiers.
Advanced GaN Technology
Utilizes high-efficiency Gallium Nitride on Silicon Carbide (GaN-on-SiC) devices for superior power density and thermal management.
Built-in Protection
Includes integrated circuitry for over-temperature protection and VSWR (Voltage Standing Wave Ratio) protection to prevent damage from signal reflection.
Compact & Rugged Design
Housed in a precision-machined aluminum alloy chassis, designed to withstand harsh industrial and relative evironments.
Customization Options
Frequency range and output power can be customized according to specific requirements.
Applications
- Electronic Countermeasures (ECM): Ideal for signal jamming and broad-spectrum interference systems
- Test & Measurement: A reliable lab-grade power source for EMC testing and antenna measurements
- Communication Systems: High-power booster for 5G, Wi-Fi 6, and satellite ground stations
- Radar Systems: Pulse and CW (Continuous Wave) applications for modern radar detection
Technical Specifications
| Parameter |
Specification |
| Frequency Range |
400-3000MHz |
| Output Power (P_sat) |
≥50W |
| Gain |
≥50dB |
| In-band Gain Flatness |
≤5.0dB |
| Working Current |
≤5.5A |
| Connector |
SMA-Female |
| Power Supply & Control Interface |
DB7W2 |
| VCC Power Supply & Maximum Voltage |
+28V, +32V |
| Dimension |
180×90×25mm (Not including connectors) |
| Net Weight |
1kg |
| Power Supply Wire |
Red+Black+Enable wire |
| Working Temperature |
-40℃ to +55℃ |
